Specification

• Printer Model

  GP-1264D

• Print Mode

  Direct thermal

• Print Command

  TSPL

• Resolution

  203DPI

• Print Speed

  2~8 inch/s（200mm/s）

• Print Width

  104mm（max）

• Head Position Detection

  Microswitch

• Media Detection

  Reflective Sensors

• Head Position Detection

  Microswitch

• Memory

  DRAM:8MB FLASH:4MB

• Interface

  Standard:USB
  Optional:USB+Bluetooth、USB+WiFi

• Graphics

  Monochrome PCX, BMP and other image files can be downloaded to FLASH/DRAM

• Barcode/QRcode

  CODE128、EAN128、ITF、CODE39、EAN13、EAN13+2、EAN13+5、EAN8、EAN8+2、EAN8+5、CODABAR、POSTNET、UPC-A、UPC-A+2、UPC-A+5、UPC-E、UPC-E+2、UPC-E+5、CPOST、MSI、MSIC、PLESSEY、ITF14、EAN14、QRCODE

• Character Set

  Common single-byte fonts：FONT 0 to FONT 8

• Character Enlargement / Rotation

  1 ~10 times enlargement in portrait and landscape orientation; 0°, 90°, 180°, 270°degree rotation printing

• Media Type

  Continuous, die-cut, fan-fold, black mark

• Media Width(with liner)

  25mm-118mm

• Media Core Diameter

  25.4mm~38mm

• Media Thickness

  Max 0.254mm，Min 0.06mm

• Media Roll Size

  130mm(OD)

• Paper Output Method

  Front paper output

• Media Handling

  Tear-off

• Power Input

  Input：DC24V 2.5A

• Operation Environment

  5~40℃，20%~90%non-condensing

• Storage Environment

  -25~55℃，20%~93%non-condensing

• Printer N.W

  1.356 kg

• Printer Dimension (D×W×H)

  219mm×178mm×159mm

• Packing Dimension (D×W×H)

  312mm×230mm×225mm

• Box Dimension

  715mm×475mm×332mm

• Packing G.W.(kg)

  13.856 ‬kg

• Quantity/Box

  6

• Print Head (reliability)

  30 km

• Printer Certificate

  CCC、RoHS、SRRC
