Specification

• Model

  GP-M322P

• Print Method

  Direct thermal

• Print Command

  TSPL（Standard ），CPCL，ESC/POS

• Resolution

  203DPI

• Print Speed

  100mm/s（Continuous）; 70mm/s（label paper）

• Print Width

  72mm

• Overheat Protection

  Thermistor

• Head Position Detection

  Microswitch

• Media Detection

  Thru Beam Sensor, reflective sensor

• Sensor Position

  Left

• Memory

  RAM:4M FLASH:16M

• Display

  128×64 OLED

• Button

  POWER/SAVE, FEED/SET, MENU

• Interface

  USB+Bluetooth

• USB Type

  Type-C

• USB VID PID

  VID：0471, PID：0055

• Max.Printing Specifications

  72mm×300mm

• Graphics

  Monochrome PCX, BMP and other image file printing

• Barcode

  CODE128、EAN128、ITF、CODE39、EAN13、EAN13+2、EAN13+5、EAN8、EAN8+2、EAN8+5、CODABAR、POSTNET、UPC-A、UPC-A+2、UPC-A+5、UPC-E、UPC-E+2、UPC-E+5、CPOST、MSI、MSIC、PLESSEY、ITF14、EAN14

• QR Code

  QRCODE、PDF417

• Character Set

  Simplified Chinese（GB18030）：16*16、20*20、24*24
  Traditional Chinese（BIG5）：24*24
  Korean（KSC5601）：24*24

• Character Enlargement / Rotation

  1 ~10 times enlargement in portrait and landscape orientation; 0°, 90°, 180°, 270°degree rotation printing

• Media Type

  Thermal paper, label paper, reverse black mark paper

• Media Width

  25-80mm

• Media Thickness

  0.06mm-0.17mm

• Media Roll Outer Diameter

  51mm

• Media Output

  Top paper output

• Power Supply

  Input：DC 5V 2A

• Charging Time

  ≤3h

• Battery Standby Time

  ≥96h

• Battery Print Mileage

  ≥200m（12.5% printing rate）（25℃）

• Battery Cycle Life

  500times，≥80%

• Battery Capacity

  7.4V/2600mAh

• Working Environment

  5~40℃，20~90%non-condensing

• Storage Environment

  -20~55℃，20~93%non-condensing

• Pressure

  86~106kPa

• Printer N.W (without battery)

  240g

• Printer N.W (with battery)

  346g

• Printer G.W Weight (with battery)

  500g

• Printer Dimensions

  114mm×105mm×60mm

• Packing Dimension

  160mm×145mm×70mm

• Box Dimension

  380mm×355mm×240mm

• Quantity / Box（PSC）

  18

• Box Weight（KG）

  9.75KG

• Print Head (reliability)

  Receipt: ≥150km (25% print density or less)/100 million pulses (25°C)

  Label: ≥50km (25% print density or less)/100 million pulses (25°C)

• Printer Certificate

  CCC、SRRC、RoHS、CE、FCC、UN38.3、IP42
